GARMIN GPSMAP 8612 12" Chartplotter

GARMIN GPSMAP 8612 12" Chartplotter

Part #: 010-02092-01

SERIOUS CRUISERS, SAILORS AND SAIL RACERS DEMAND SERIOUS EQUIPMENT

Build your marine system around these fully networkable units with HD in-plane switching (IPS) touchscreen displays for wider viewing angles, superior clarity and sunlight readability — even with polarized sunglasses.

Get wider viewing angles and superior clarity on the 12” touchscreen with a full HD IPS display.

It’s compatible with premium maps and charts for the best in Garmin navigation.

Easily build your marine

SERIOUS CRUISERS, SAILORS AND SAIL RACERS DEMAND SERIOUS EQUIPMENT

Build your marine system around these fully networkable units with HD in-plane switching (IPS) touchscreen displays for wider viewing angles, superior clarity and sunlight readability — even with polarized sunglasses.

Get wider viewing angles and superior clarity on the 12” touchscreen with a full HD IPS display.

It’s compatible with premium maps and charts for the best in Garmin navigation.

Easily build your marine system using the best of network connectivity.

From ANT® technology to Wi-Fi® networking, there are countless ways to connect to your system.

Take the guesswork out of sailing with clear laylines and more — right on the screen.

With SmartMode™ station controls, everything is designed to give you quick, one-touch access to the information you need.

Made for your helm.

HD IPS DISPLAY WITH TOUCHSCREEN

This large 16” display offers wider viewing angles, superior clarity and sunlight readability, even with polarized sunglasses.

SIMPLE, ATTRACTIVE MOUNTING OPTIONS

You can install multiple displays, either flat mounted edge-to-edge for a sleek glass helm look or mounted flush — creating a stunning helm.

GRID™ 20 REMOTE CONTROL

The optional, easy-to-use GRID 20 remote input device provides intuitive remote access and control of your entire Garmin marine system.

Sail and navigate with ease.

GARMIN SAILASSIST™ SAILING FEATURES

View laylines, race start line guidance, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider, wind angle, set and drift, wind speed and more.

PRELOADED MAPPING

Experience unparalleled coverage and detail with preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps featuring integrated Garmin and Navionics® content and Auto Guidance technology1.

Connect to everything on your boat.

GARMIN MARINE NETWORK

If you have multiple Garmin devices on your boat, you can share information — such as maps, user data, radar and IP cameras — among them.

NMEA 2000® AND NMEA 0183 NETWORKS

Connect to autopilots, digital switching, weather, Fusion-Link™ audio system, media, VHF, AIS and more from one screen.

ACTIVECAPTAIN® APP

Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications2, software updates, Garmin Quickdraw™ Community data and more.

INTEGRATED BLUETOOTH® AND ANT TECHNOLOGIES

Connect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.

ONEHELM™ FEATURE

This exclusive feature brings together all the operations and capabilities of third-party devices, such as EmpirBus™ digital switching, on one screen.

SMARTMODE STATION CONTROLS

Get quick, one-touch access to the information you need to ease high-stress situations such as docking. You can incorporate networked sonar, radar, cameras, media and more.

ENGINE CONNECTIVITY

Connect this chartplotter to different kinds of engines — including select Mercury and Yamaha® models — to see RPMs, fuel flow, temperature, trim and other important information at a glance. You may need additional hardware, so be sure to check with your engine manufacturer.

See the world below.

PANOPTIX™ SONAR SUPPORT

Pair your chartplotter with Panoptix PS51 FrontVü forward-looking sonar, which helps you avoid running aground.

Manage your marine experience using the free ActiveCaptain app

Show the sea what you’re made of with the quatix® 6X Solar smartwatch.

Make confident decisions using GNX™ Wind Instruments.

Manufacturer: Garmin

Part #: 010-02092-01

Length/Depth: 3 in.

Width: 11.90 in.

Height: 8.50 in.

Weight: 6 lbs.

Screen Size (diagonal in.): 11.60

Display Resolution: 1920 x 1200

Touchscreen: Yes

Buttons: No

Pre-loaded Charts: Yes

Integrated GPS: Yes

Integrated Sonar: No

Local WiFi: Yes

NMEA 2000: Yes

NMEA 0183: Option

Network Ports: 2

J1939 Ports: 1

Video In Ports: 1 BNC & 1 HDMI

Video Out Ports: 1 HDMI

Supply Voltage: 10 to 32 VDC

Max Current Draw: 6 Amps

Waterproofing: IPX7

Includes Mount: Yes
